The Siemens part number 6ES7145-1GB30-0XB0 is an expansion module for the SIMATIC S5/S7 series, specifically designed for the ET 200X platform. It is an analog output module, providing 2 analog outputs (2AO) with a range of +/-10V, 11-bit resolution, and sign bit. The module is designed for use in industrial settings and is rated for IP66/67 protection against environmental factors such as dust and water.
Technical Specifications
- Analog Outputs: 2AO
- Output Range: +/-10V
- Resolution: 11-bit + sign bit
- Connection: 2/4-wire connection
- Terminal: 2x5-pin M12
- Protection Rating: IP66/67
