| Condition | SKU | Stock | Location and Best Delivery Date | Price | Purchase |
|---|---|---|---|---|---|
| New Factory Sealed | 6AV6643-0BA01-1AX0-FS-USA | 1 | United States | $3,720.75 |
|
| New Surplus | 6AV6643-0BA01-1AX0-NS-USA | 1 | United States | $3,308.25 |
|
| Refurbished | 6AV6643-0BA01-1AX0-R-USA | 6 | United States | $1,432.20 |
|
| 6AV6643-0BA01-1AX0-R-EU | 6 | Europe | $2,482.80 |
|
The Siemens part number 6AV6643-0BA01-1AX0 is an OP 277 6" operator panel with a 5.7" TFT display and 4 MB configuration memory. It is configurable with WinCC flexible 2005 or higher. This panel is designed for use in industrial automation settings, particularly with Siemens' SIMATIC HMI systems.
Technical Specifications
- Display: 5.7" TFT
- Configuration Memory: 4 MB
- Compatibility: Configurable with WinCC flexible 2005 or higher
Alarm/Error Codes
No specific information on alarm or error codes for this product was found in the provided search results.
User Manuals
The user manual for the Siemens 6AV6643-0BA01-1AX0 is likely to be part of the larger documentation set for the SIMATIC HMI system, which includes the WinCC flexible software. The user manual would provide detailed instructions on the panel's operation, configuration, and troubleshooting.
Troubleshooting
Troubleshooting for this product would likely involve checking the panel's configuration and communication with the SIMATIC HMI system. The user manual and technical support resources from Siemens would be essential in resolving any issues that may arise.
Programming
The programming of the 6AV6643-0BA01-1AX0 is done using the WinCC flexible software, which is part of the SIMATIC HMI system. This software allows users to configure the panel's display, input/output operations, and communication with other devices in the system.
Installation
The installation of the 6AV6643-0BA01-1AX0 would typically involve mounting the panel in a suitable location, connecting it to the SIMATIC HMI system, and configuring the panel's settings using the WinCC flexible software. The panel's dimensions are 16.0" x 4.0" x 12.0" (40.6 cm x 10.2 cm x 30.5 cm), and it weighs 3 lbs 16.0 oz (1.8 kg).
