The Siemens part number 6AG1332-5HF00-4AB0
This is a digital output module, specifically a relay output module SM 322, designed for use in the S7-300 automation system. This module is part of the S7-300 documentation package and is described in the S7-300 Module Data Manual.
Technical Specifications
The module has the following technical specifications:
- Rated Load Voltage: 230VAC/5A
- Number of Outputs: 8
- Output Current: 5A
- Isolation Rating: SELV circuit with rated isolation voltage (24 V to L1) and test voltage 250 V AC/2800 V DC
- Safety Class: IEC 536 (DIN VDE 0106, Part 1) I, with protective conductor
- Efficiency: 84%
- Power Consumption: 143 W
- Power Loss: 23 W
Alarm/Error Codes
The manual does not provide specific information on alarm or error codes for this module. For general information on error handling and troubleshooting, refer to the S7-300 Module Data Manual.
User Manual
The user manual for this module is part of the S7-300 documentation package and is available online. It provides detailed information on the module's properties, connection and block diagrams, technical data, and special features.
Troubleshooting
Troubleshooting for this module is covered in the S7-300 Module Data Manual. The manual includes general information on troubleshooting and error handling, as well as specific guidance for the module's properties and technical specifications.
Programming
The module can be programmed using the STEP 7 user program. The structure of parameter sets (data records 0, 1, and 128) is described in the system data section of the appendix, and the structure of diagnostic data (data records 0 and 1) is also described in the appendix. For more information on programming, refer to the S7-300 Module Data Manual.
Installation
For information on installation and wiring, refer to the S7-300, CPU 31xC, and CPU 31x Operating Instructions: Installation. These instructions are available online and provide detailed guidance on the installation and wiring of the module.
Compatibility
The module is designed for use in the S7-300 automation system and is compatible with other modules in this system. For more information on compatibility and integration with other modules, refer to the S7-300 Module Data Manual.
Download the Data Sheet Go to product
